ACI 318-11 SMRF Footing Design

Description of Software Tool:

This Excel Software Tool is provided for the design of American Concrete Institute (ACI) Building Code Requirements for Structural Concrete (318-11) rectangular Reinforced Concrete (RC) Spread Footings for 2-column frames which are part of the Lateral Force Resisting System (LFRS) for a building structure.

This Software Tool consists of the following Design Worksheets included within:

• SMRF Foundation Design;

• Footing Loads;

• Fixed Base Condition;

Users Guide to Software Tool - Page 1 (Brief Description)
