AISC 341-10 SCBF - Steel Pipe Braces

Description of Software Tool:

The above referenced Excel Software Tool is provided for the design of AISC 341-10  Special Concentric Braced Frames (SCBF) with 2 columns using Pipe Braces, which are considered to be pinned at all connections.

Connection Procedure 1 is used for connections, defined here as using the procedure used in AISC 341-05 Example 3.10 (SCBF Brace-to-Beam Connection Design) and Example 3.11 (SCBF Brace-to-Beam/Column Connection Design) and updated for AISC 341-10 terminology and criteria. Briefly summarized, Brace-to-Beam connections above and below the Center Beam consist of a single gusset plate with 3/8” stifferer plates to which both braces are welded; slit braces are reinforced at the connection with welded cover plates cut from brace sections. The same pipe brace reinforcement detail is used for Brace-to-Beam/Column Connection Design.

This Software Tool consists of the following Design Worksheets included within:

• 1. SCBF Layout;

• EQ Force Distribution;

• EQ Overturning;

• 2a. Pipe Brace Design - Top Floor;

• 2b. Pipe Brace Design - Center Floor;

• 2c. Pipe Brace Design - Bottom Floor;

• 3. SCBF Column Design;

• 4a. SCBF Beam Design - Top;

• 4b. SCBF Beam Design - Center;

• 4c. SCBF Beam Design - Bottom;

• 5. SCBF Top Brace to Column Connection Design;

• 6. SCBF Center Brace to Beam Connection Design;

• 7. SCBF Bottom Brace to Column Connection Design;

Users Guide to Software Tool - Page 1 (Brief Description)
